Weight : and Dimensions See individual modules
Voltage : 230 V
Input Fuse : DDE: 2A / JT: 4A
Output Peak Power : DDE: 150 W per tool
Nominal Power : JT: 700 W
Temperature selection : JT: 150-450ºC (300-840ºF) or Cool mode: Temp Off
DDE: 90-450 ºC (190-840 ºF)
Idle Temp. Stability (still air) : DDE: ± 1.5 ºC (± 3 ºF)
Ambient operating temp. : 10-40 ºC (50-104 ºF)
Air Flow Regulation : JT: 10-50 SLPM
Flow rate : MVE: 15 SLPM
Vacuum : JT: 30% / 228 mmHg / 9 inHg
Vacuum (at 6 Bar) : MVE:90%/680 mmHg/26.8 inHg
Air pressure : 4-6 Bar (Max. 6 Bar)
Rated current : JT: 3A
Tip to ground resistance : DDE: < 2 ohms
Tip to ground voltage : DDE: < 2 mV RMS
Communication connectors : JT: USB-B
Robot connector : DDE:USB-A/USB-B/Peripherals
Robot connector : DDE: RJ12 for RS-232 protocol
Pedal connection : JT and MVE: P-005 Pedal
ESD Safe
Package weight : 15.863 kg (34.97 lb)
Package dimensions : 480 x 370 x 380 mm
Weight : 14.128 kg (31.14 lb)
