Weight : 8.348 kg (18.40 lb)
Dimensions : See individual modules
Voltage(AC) : 230V
Input fuse : 2A
Output peak power : 150W per tool
Temperature selection : 90-450 ºC (190-840 ºF)
Idle temp. stability (still air) : ±1.5 ºC (±3 ºF)
Tip to ground resistance : <2 ohms
Tip to ground voltage : <2 mV RMS
Ambient operating temp. : 10-40 ºC (50-104 ºF)
Communication connectors : USB-A / USB-B / Peripherals
Robot connector : RJ12 for RS-232 protocol
Vacuum at 6 Bar (MVE-A) : 90% / 680mmHg / 26.8inHg
Flow rate (MVE-A) 15 SLPM
Air pressure (MVE-A) : 4-6 Bar
ESD safe
Package weight : 9.854 kg (21.72 lb)
Package dimensions : 368 x 474 x 195 mm
