Weight 9.253 kg (20.39 lb)
Dimensions See individual modules
Voltage(AC) 230V
Input fuse 2A
Output peak power 150W per tool
Temperature selection 90-450 ºC (190-840 ºF)
Idle temp. stability (still air) ±1.5 ºC (±3 ºF)
Tip to ground resistance <2 ohms
Tip to ground voltage <2 mV RMS
Ambient operating temp. 10-40 ºC (50-104 ºF)
Communication connectors USB-A / USB-B / Peripherals
Robot connector RJ12 for RS-232 protocol
Vacuum (MSE-A) 75% / 570mmHg / 22.4inHg
Flow rate (MSE-A) 9 SLPM
ESD safe
Package weight 10.393 kg (22.91 lb)
Package dimensions 368 x 474 x 195 mm
